DPLI 850W-X
Salient Features of DPLI 850W-X
Micro Controller
Based Smart SMPS Charger
Temperature Protection
Over Temperature Protection
Charging
Multistage CC-CV Charging
Short Circuit Protection
Short Circuit Protection
Battery Protection
Battery Reverse Polarity Protection
Rating
48V 10A, 60V 10A, 72V 10A
BMS
BMS Auto Fault Reset Switch
Maximum Power
1000W
Voltage Protection
Over Voltage & Over Current Protection
Communication
CAN (optional)
| AC RMS Input Voltage Range | 160VAC – 285VAC RMS, Single Phase |
|---|---|
| Maximum AC RMS Input Current | 6 A (±1 A) |
| Maximum AC Input Power | 943 W (±50 W) |
| AC Input Frequency | 47Hz – 53Hz |
| Peak Efficiency | > 90% |
| Power Factor | 0.6 @ 230 Vac |
| Inrush Current | < 84 A |
| Rated Power | 850 W (±50 W) |
|---|---|
| Maximum DC Output Current | 10 A (±1 A) |
| Maximum DC Output Power | 840 W @ 230 Vac |
| Maximum Output Voltage | 84.0 V (±0.2 V) |
| Ripple Voltage (pk-pk) | 20 mV (±10 mV) |
| Ripple Current (pk-pk) | 300 mA (±10 mA) |
| Line Regulation | < 2% |
| Load Regulation | < 2% |
| Battery Type | Li-ion (Lithium Ion) |
| Over Current Protection | >= 10 A + 1 A |
|---|---|
| Over Voltage Protection | 84.0 V (+0.2 V) |
| Short Circuit Output Protection | 40 A |
| Over Temperature Protection | Provided |
| Reverse Battery Polarity Protection | Provided |
| Soft start | YES |
|---|---|
| Pri-charging function | PROVIDED |
| Power On | Green LED |
|---|---|
| Charging On | Red LED Blink |
| Full Charge | Green LED Solid |
| Buzzer | After Full Charge (30 seconds) |
| DC Output Connector | EMO / SBS75X / Chogori |
|---|---|
| AC Input Connector | 16A, 3 PIN Inbuilt Top |
| Input Wire Length | 1500mm (±50mm) |
| Input Wire Copper | 1 SQ mm, 3 Core |
| Output Wire Length | 600mm (±50mm) |
| Output Wire Copper | 3 SQ mm, 2 Core |
| Operating Temperature | 0°C to 50°C |
|---|---|
| Humidity | 5% to 90% (Non-Condensed) |
| Storage Temperature | 0°C to 50°C |
| Testing Result @ 95% RH, 38°C | Passed |
| EMI | Inbuilt EMI Filter |
|---|
| Enclosure Protection | IP21 |
|---|---|
| Dimensions (L × W × H) | ~(218mm × 105mm × 70mm) |
| Cooling | Forced Air Cooling |
| Drop Test Result (If Applicable) | PASS |
| Weight | ~1.900 Kg |
